Uses: UPS / EPS applications, power systems, telecommunications systems, security lighting, auto control system, storage cycle in solar and wind energy systems, other general purposes.
Technicial Specifications
Rated Voltage 12V
Capacity 9 Ah
Rated Capacity 9 Ah / 20 hr (0.45 A – 10.5 V)
6.99 Ah / 3 hr (2.33 A – 10.5 V)
5.94 Ah / 1 hr (5.94 A – 9.6 V)
Max. Discharge Current 135 A (5 s)
Charge Current 25oC Max. 2.25 A, Recommended 0.9 A
Standby Mode Usage 25oC 13.5 ~ 13.8 V, Recommended 13.5 V (-18 mV/oC)
Balanced Use 25oC 13.8 ~ 14.1 V, Recommended 14.1 V (-24 mV/oC)
Cycle Usage 25oC 14.4 ~ 15 V, Recommended 14.4 V (-30 mV/oC)
Internal Resistance Full charge at 25oC: 20 mΩ
Self Discharge Capacity decreasing by 3% per month at 25oC
Operating Temperature -20oC ~ +50oC (charge, discharge, storage)
Pole Head F187 / F250
Design Life 5 years
Outer Case Material ABS
Dimensions (LxWxH) – Total Load. 152 x 65 x 94mm – 100mm
Weight 2.6 kg
